CYCLINGCERAMIC- Bottom bracket – Bottom bracket – PF30 Shimano


SKU: CCBBPF30SHIMB Categories: ,

CyclingCeramic bottom brackets are combined with low friction ceramic bearings and are more durable than standard bearings. The high quality of the bottom bracket housings allows them to achieve high performance. They have been designed to offer a lightweight package and thanks to the design of the seals, allow maximum protection.

The extreme hardness of the CyclingCeramic balls gives rise to a 4 to 5 times longer bearing life compared to the standard bearings, the special grease keeps your bearings sealed and protects them from external elements that can impede the proper functioning.

Silicon nitride balls are used to improve the performance of bearings. Ceramic balls are lighter, stiffer, smooth, hard, resistant to corrosion. They require less lubrication and have lower thermal expansion than their steel counterparts. The beads are polished for 45 days continuously to obtain rounder and smoother balls. This makes it possible to reduce the contact surface to the maximum.


Details :

  • Compatible with  24 mm crankset (Shimano)/ internal frame 46 mm / width 68 mm (pressfit)
  • Use road or MTB.
  • Durability 3 to 5 times longer than conventional bearings.
  • Ceramic beads 58% lighter, 121% stronger and 68% harder than steel balls.
  • Grade 3 ceramic beads (polished for more than 45 days) for almost non-existent friction.
  • Case designed, machined and assembled in France in the CyclingCeramic workshop.
  • Weight: 80g


Bottom bracket width 68
Bottom bracket mount PressFit 30
Frame Inner Diameter 46
Bearing Quality Ceramic
Spindle 24 mm
Crank Standard Shimano Hollowtech II
Additional information
Weight 1 kg
Dimensions 11 x 11 x 11 cm

Black, Red
